Ziewnic Li-Box 48V 100AH 6000 Cycles IP 21 LiFePo4 Lithium Battery Price in Pakistan
Original price was: ₨ 320,000.₨ 212,000Current price is: ₨ 212,000.
Add ₨ 100 more to get free shipping!
Description
- Compatible with Ziewnic inverter, Inverex, Voltronic Power, Crown, Sako, Next Power, Solis, Growatt, Sofar, Solax, Deye, Srne, Pylon Tech, ChuangHuiYuan, Sumry, SoroTec, Megarevo, Goodwe, Must, Xindun (Supported all kinds of inverters at least 90%)
- 6 Years Warranty, 12+ years life design. 6000 life cycles (Charge/discharge) superior safety and reliability.
- Available in 24V & 48V variations.
- Ziewnic wall-mounted lithium battery with large LCD.
- Equipped with the best brand cell such as CATL, GOTION, or BYD.
- Intelligent BMS management system to optimize performance.
- High density, compact design & weight.
- Built-in 1,2A cell equalizer can balance all cells in a short time
- Charge & discharge current is up to a Maximum of 100A and the cold start impulse current is 1000A.
- Excellent standby self-consumption as low as 4mA.
- Wall-mounted design, easy installation.
- All-around protection and unattended operation.
- Optional for LCD or communication (CAN/RS485/RS232).
- Application for off-grid/hybrid/solar system/UPS/Inverter/Storage power system.
- Excellent standby self-consumption as low as 4MA. Automatically output cut off after 30 days no-charge & discharge to ensure security (also can cut off output by manual operation)
- Load capacity 25.6V 100AH (2560WH). 51.2V 100AH (5120WH) Battery bank.
- Commercially approved fire certificate UN38.3 & other safety standard IEC62619, MSDS & CE.
Li-BOX (48V – 100AH) datasheet
| Battery Type | LiFePO4 |
| Normal Battery Voltage (VDC) | 51.2V |
| Normal Capacity (25C, 0.2C) (WH) | 5120WH |
| Voltage Window (VDC) | 44.8~58.4V |
| Folar Charge Voltage (VDC) | 56.2V |
| Max. Continue Discharge Current (A) | 100 |
| Max. Pulse Discharge Current (A) | 100A 30 Sec. |
| Max. Continue Charge Current (A) | 100 |
| Case Design | Powerwall Design |
| Cycle Life (+25C 0.2 80%DOD) | >6000 Cycles with 6 Years Warranty) |
| Cell Equalizer Current (A) | 1~5A Max |
| Terminal | M8 |
| Storage Temperature | 0°C~30°C |
| Storage Duration | 4 months at 25°C |
| Safety Standard | UN38.3, IEC62619, MSDS,CE |
| IP Degree | IP21 |
| PROTECTION | |
|---|---|
| Protection | Over Charge Protection, Over Discharge Protection, Over Current Protection, Short Circuit Protection, Over Temperature Protection |
| AMN | ENT | |
| Noise (dB) | <40dB (1 Meter) |
| Working Temperature | -20°C~+50°C |
| Humidity | 0~95% (no condensation) |
| Sea Level (m) | -1500 |
| DIMENSION | |
| LxWxH mm | L625*W390*H210 |
| Weight (NW Kg) | 43.0Kg |
| Weight (GW Kg) | 44.0Kg |
